Tongue and groove joint with sliding dovetail batten
Joint family: dovetail (Schwalbens.), butt (Stoß) Joining principle: rigid interlocks
Opened joint
Closed joint
Closed joint with dimensions
Opened joint with dimensions
Description
no text yet.
Sources
Properties
Geometry of elements
- board
Geometry of joint
- I-I-Joint
Orientation of the cross-section
- horizontal
Number of elements
4
Degrees of freedom
- y-axis
Absorbable loads
- x (pressure)
- x (tension)
- z (pressure)
- z (tension)
- a (moment)
- b (moment)
- c (moment)
Number of assembly steps
1
Connector used
with spline
Traditional use case
-
